 ● Battery Holders (Coin type) 電池座:



        FAIRPLY offer various battery holders that can fit CR1220, CR2032, CR2450 button battery for PC application. Vertical and R/A orientation options can meet different application and requirement. The height for R/A orientation covers from 5.1mm to 8.5mm that give customers more flexibility.



Type

Packaging

Part Nos

XX2032

1. Battery: Ф20/H3.2mm

2.2Pin(DIP), Thru-hole Black, Stand off height: 0.5mm

3.  H=8.8mm

4. Color : Black

5. Materials: PBT+G.F

Tray

BAT HO-2-G

XX2032

1. Battery: Ф20/H3.2mm

2. 2Pin(SMD), Thru-hole, latch width: 3.26 , with-post

3. H=4.85mm

4. Color : Brown

5. Materials: PPS+G.F

Reel/Tray

BAT HO-SMD-21-G

XX2032

1. Battery: Ф20/H3.2mm

2. 2Pin(SMD), Thru-hole, latch width: 4.39, non-post

3. H=5.3mm

4. Color : Black, Brown

5. Materials: LCP+G.F/PPS+G.F

Tray

BAT HO-SMD-22-G (黑HF)

BAT HO-SMD-23-G (棕)

Reel

BAT HO-SMD-23-R-G (棕)

XX2032

1. Battery: Ф20/H3.2mm

2. 2Pin(SMD), Thru-hole,

with-post

3. H=5.3mm

4. Color : Brown

5. Materials: PPS+G.F

Reel/Tray

BAT HO-SMD-B-G

XX2032

1. Battery: Ф20/H3.2mm

2. 2Pin(SMD), non-post

3. H=5.5mm

4. Color : White

5. Plating : Gold

6. Materials: LCP+G.F

Tray

BAT HO-SMD-W-G

XX2032

1. Battery: Ф20/H3.2mm

2. 3Pin(DIP), Thru-hole, vertical

3. Color : Black

Tray

BAT HO-V-G

CR1220

1. Battery: Ф12.5/H2.0mm

2. 2Pin(SMD) Thru-hole , with-post

3. H=4.0mm

4. Color : Brown

Reel/Tray

BAT HO-SMD-1220-G

CR2450

1. Battery: Ф24.5/H5.0mm

2. 2Pin(DIP), Thru-hole, (HF)

3. H=9.5mm

Tray



XX2032

1. Battery: Ф20.0/H3.2mm

2. 2Pin(DIP), Thru-hole

3. H=7.6mm

Tray

BAT HO-8-G



※ Remark :

1. Other styles, please contact our sales.

2. UL94V-0 & RoHS Compliance



● Battery Holder (Clips) 電池扣/電池彈片:

P/N: BAT-C1156-G

P/N: BAT-C1201-G

P/N: BAT-C1202-G

P/N: BAT-C1203-G

SMT, Size: 11.6mm

(FOR LR44/AG13/303)

SMT, Size: 12mm

(FOR 1216/1220/1225)

SMT, Size: 12mm

(FOR 1216/1220/1225)

DIP, Size: 12mm

(FOR 1216/1220/1225)



P/N: BAT-C1600-G

P/N: BAT-C1601-G

P/N: BAT-C1602-G





SMT, Size: 16mm

(FOR 1612/1616/1620/1632)

DIP, Size: 16mm

(FOR 1612/1616/1620/1632)

SMT, Size: 16mm

(FOR 1632)





P/N: BAT-C2001/2-G

P/N: BAT-C2003/B-G

P/N: BAT-C2004G-G

P/N: BAT-C2018-G

SMT, Size: 20mm

(FOR 2020/2025/2032)

DIP, Size: 20mm

(FOR 2020/2025/2032)

SMT, Size: 20mm

(FOR 2020/2025/2032)

SMT, Size: 20mm

(FOR 2020/2025/2032)



P/N: BAT-C2005-G

P/N: BAT-C2007-G

P/N: BAT-C2012-G

P/N: BAT-C2016-G

DIP, Size: 20mm

(FOR 2020/2025/2032)

SMT, Size: 20mm

(FOR 2032X2PCS)

SMT, Size: 20mm

(FOR 2032)

SMT, Size: 20mm

(FOR 2016/2020/2025)



P/N: BAT-C2403-G

P/N: BAT-C2413-G

P/N: BAT-C2412-G

P/N: BAT-C2430-G

DIP-A, Size: 24mm

(FOR 2450)

DIP-B, Size: 24mm

(FOR 2450)

SMT, Size: 24mm

(FOR 2450)

DIP, Size: 24mm

(FOR 2430)

P/N: BAT-C2417-G

P/N: BAT-C2418-G




DIP, Size: 24mm

(FOR 2477)

SMT, Size: 24mm

(FOR 2477)



※ Remark :

1. Other styles, please contact our sales.

2. Nickel plated.

3. High reliability.

4. RoHS Compliance.
